Water Heater Tank Booster Guide

In this blog post, you’ll read:A water heater tank booster is a device that can be installed on a traditional tank-style water heater. It enhances the amount of hot water available for use. The device works by mixing hot water from the tank with cold water. Yet, this increases the volume of hot water available. Moreover, it also extends the time the hot water stays hot. The water heater tank booster consists of a thermostatically controlled mixing valve. This valve will be installed on the hot water outlet of the water heater tank. The valve mixes the hot water with cold water to achieve the desired temperature and volume of water. The booster adjusts to provide the required temperature that meets the home's needs.
Table of Contents

Introduction of Heter tank booster

A water heater tank booster is a device that can be installed on a traditional tank-style water heater. It enhances the amount of hot water available for use. The device works by mixing hot water from the tank with cold water. Yet, this increases the volume of hot water available. Moreover, it also extends the time the hot water stays hot.

The water heater tank booster consists of a thermostatically controlled mixing valve. This valve will be installed on the hot water outlet of the water heater tank. The valve mixes the hot water with cold water to achieve the desired temperature and volume of water. The booster adjusts to provide the required temperature that meets the home’s needs.

Water heater tank boosters are beneficial for larger households. It is also helpful for those with high hot water demand. They can help to prevent the need for a larger, more expensive water heater. They also improve the existing water heater’s efficiency by lowering the time it takes to heat the water.

water heater tank booster
water heater tank booster

Why do we need a water heater tank booster?

A water heater tank booster increases the amount of hot water available from a hot water tank. This is achieved by increasing the water temperature in the tank to a higher temperature than the standard setting.

By increasing the water temperature in the tank, the booster allows the hot water to last longer before running out. It can be beneficial during peak usage times like mornings and evenings.

Maintaining a higher temperature in the tank requires less energy to heat the water as it is used. This will result in lower utility bills over time.

Temperature required for tank booster.

The temperature required for a tank booster can vary depending on the specific model and application. Yet, in general, tank boosters are designed to maintain a safe and suitable temperature at the tap.

The recommended temperature for a tank booster is usually around 120°F (49°C). This temperature is hot enough to provide a comfortable shower or bath. Yet, it also prevents scalding. This temperature adjusts as needed to suit your specific needs and preferences.

It is vital to note that temperatures above 120°F can increase the risk of scalding. It mainly reduces the risk in children and people with sensitive skin. Additionally, temperatures above 140°F can cause severe burns in seconds. So, it is recommended to keep the temperature of your tank booster at or below 120°F for safety and comfort.

How does the water heater tank booster work?

A water heater tank booster works by mixing warm water from the tank with cold water to achieve a higher volume of usable hot water. Here’s how it works:

A water heater tank booster, often referred to as a “hot water booster” or “thermostatic mixing valve,” is a device designed to increase the capacity of a traditional water heater without the need to invest in a larger tank. It does this by regulating the temperature of the stored water, allowing it to be stored at a higher temperature and then mixed with cold water when being dispensed to ensure safe and consistent temperatures. Here’s a step-by-step explanation of how it works:

  • Storing Water at Higher Temperatures:
    • Without a booster, most residential water heaters are typically set to store water at 120°F (49°C) to prevent the risk of scalding.
    • With a tank booster, the water heater’s thermostat can be increased to store water at a much higher temperature, often around 140°F (60°C) or more. This higher temperature helps in reducing the risk of Legionella bacteria growth, which can cause a form of pneumonia known as Legionnaires’ disease.
  • Mixing Hot with Cold:
    • When you open a hot water tap in your home, the water from the heater, now at a higher temperature, flows into the mixing chamber of the tank booster.
    • Simultaneously, cold water is also introduced into this mixing chamber. The tank booster then mixes these two streams, producing water at a safe, consistent temperature, usually around 120°F (49°C), before it is sent to your tap.
  • Increased Effective Capacity:
    • Because the water is stored at a higher temperature and mixed with cold water before it reaches the tap, you effectively get more hot water than the tank’s rated capacity. For example, a 40-gallon tank can supply the equivalent of 60 gallons or more of usable hot water when using a tank booster.
  • Safety Features:
    • A tank booster often includes a built-in check valve to prevent mixing hot and cold water in the storage tank itself, ensuring the stored water remains at the desired high temperature.
    • Many tank boosters also have adjustable temperature settings, so you can select the exact output temperature you desire, providing more control and ensuring the water is safe for all users.
  • Energy Efficiency:
    • By allowing the tank to store hot water at higher temperatures, the frequency of the burner or heating element turning on can be reduced, leading to potential energy savings.
  • Prevention of Legionella Growth:
    • Storing water at higher temperatures significantly reduces the risk of Legionella bacteria growth in the tank, providing a safer water supply.

A water heater tank booster is an efficient solution for households frequently running out of hot water, especially during peak usage. By increasing the effective capacity of the water heater without replacing the entire unit, homeowners can enjoy longer hot showers and reduce the wait time between them.

Increased Volume:

Mixing hot water from the tank with cold water increases the volume of usable hot water. This means more hot water is available and less need to wait for the tank to reheat.

Temperature Control:

The mixing valve ensures that the mixed water is delivered at a consistent temperature. Yet, this can be adjusted to meet the needs of the household.

Tank booster helps to increase the efficiency of a traditional tank-style water heater. It provides more hot water without needing a larger or more expensive water heater. It can benefit households with high hot water demand or larger families.

Benefits of water heater tank booster

A water heater tank booster is an accessory device that can be installed on top of your existing water heater tank. Here are five benefits of using a water heater tank booster:

From Champion Plumbing

Increased hot water supply:

A water heater tank booster can increase the hot water supply by up to 45%. This means more hot water is available for longer showers, oversized baths, and other hot water activities.

Improved efficiency:

With a water heater tank booster, your water heater can operate more efficiently. The booster will help reduce the energy required to heat the water. This would help lower your energy bills.

Consistent water temperature:

A water heater tank booster can help maintain a more consistent water temperature. You won’t experience sudden fluctuations in water temperature when other appliances work simultaneously.

Extended lifespan of the water heater:

By reducing the amount of stress placed on the water heater, a water heater tank booster can help extend your water heater’s lifespan. This can save your costs in the long run by lowering the need for repairs and replacements.

Easy installation:

A water heater tank booster is easy to install and can be completed in an hour. You can improve your hot water system’s performance without extensive renovations.

Potential application of tank booster

It is used in various applications to increase the available hot water. Yet, it also improves the efficiency of your water heating system. Here are some potential applications of a tank booster:

Water heater maintenance service technician repairing gas water heater
Water heater maintenance service technician repairing a gas water heater

Residential use:

A water heater tank booster can be used in residential homes to increase the amount of available hot water for showers, baths, and other home uses. This can be especially useful for larger families or homes with many bathrooms.

Commercial use:

Tank boosters can also be used in commercial settings. It is used in hotels, restaurants, and apartment buildings. This can help ensure enough hot water is available for guests and tenants. Moreover, it also reduces energy consumption and operating costs.

Healthcare facilities:

Healthcare facilities like nursing homes and hospitals benefit from using tank boosters. It provides safe and consistent hot water for patient care and hygiene.

Industrial applications:

Tank boosters can also be used in various industrial applications. These are food processing, manufacturing, and cleaning. They can reduce operating costs by ensuring a consistent supply of hot water.

Types of water heater tank booster

A few different types of water heater tank boosters are available. Here are some types:

Electric tankless water heater booster:

An electric tankless booster is installed on the hot water supply pipe. It heats the water as it passes through the booster. This booster offers a different source of hot water and can also help reduce energy consumption.

Gas tankless water heater booster:

This booster is similar to an electric tankless water heater booster. Gas tankless booster heats the water as it passes through the booster using gas or propane. This booster can also provide hot water and help reduce energy consumption.

Recirculating pump:

A recirculating pump is installed on the hot water supply pipe. It circulates hot water through the pipes to ensure that hot water is available at the tap. This booster can help reduce water waste and increase the amount of open hot water.

When selecting a water heater tank booster, it’s vital to consider the specific requirements of your household. You need to buy this according to the plumbing system in your home. Each type of booster has its advantages and disadvantages. Yet, the best option for you will depend on factors. These are the size of your household, the availability of gas or electricity, and your budget.

Install tank booster steps.

Installing a tank booster increases the hot water capacity of your home. It mixes hot water with cold water before it enters your plumbing fixtures. Here are the steps to install a water heater tank booster:

  1. Turn off the power supply to the water heater at the circuit breaker or fuse box.
  2. Shut off the water supply valve to the water heater.
  3. Drain some of the water from the tank to relieve pressure.
  4. Identify the hot water outlet on top of the water heater tank.
  5. Remove the existing fitting from the hot water outlet.
  6. Install the included fitting adapter onto the hot water outlet.
  7. Attach the water heater tank booster to the fitting adapter using the included union.
  8. Install the mixing valve onto the cold water supply pipe using the included adapter fittings.
  9. Connect the hot water output from the tank booster to the hot water pipe.
  10. Connect the cold water input to the mixing valve.
  11. Turn on the water main supply valve and inspect for leaks.
  12. Turn on the power supply to the water heater at the circuit breaker or fuse box.
  13. Adjust the temperature setting on the mixing valve to achieve the desired hot water temperature.

Hiring a licensed plumber is recommended if you’re uncomfortable installing.

Buying guide for water heater tank booster

Home water heater, woman regulates the temperature on an electric water heater
Home water heater: a woman regulates the temperature of an electric water heater.

Here’s a buying guide to help you choose the right one:

Compatibility:

Check the compatibility of the booster with your existing water heater. Ensure it is compatible with your water heater’s size, capacity, and type.

Size:

Consider the size of the booster concerning the size of your water heater. A booster that is too large may overheat the water, while one that is too small may not provide enough hot water.

Temperature range:

Check the temperature range of the booster. Some boosters have a fixed temperature range, while others are adjustable. Make sure the booster’s temperature range matches your needs.

Energy efficiency:

Look for a booster that is energy-efficient. Some models have extra features. This is automatic shut-off or temperature control, which helps to save energy. It also helps reduce utility bills.

Brand and warranty:

Choose a well-known brand that has a good reputation for quality and reliability. Look for a booster with a warranty of at least two years.

Reviews:

Check reviews from other consumers who have bought the same booster. This will give you an idea of its performance, reliability, and customer service.

Considering these points, you can select the right water heater tank booster for your needs and enjoy the benefits of having more hot water in your home.

Significant problems in the water heater tank booster

Although tank boosters can be a helpful addition to your home’s plumbing system. Here are some main issues that you should be aware of:

Leaks:

If the connections between the water heater tank booster and your plumbing system are not installed or tightened, there is a risk of leaks. Leaks can cause water loss and lead to energy waste if hot water is lost.

Reduced water pressure:

The flow rate may be reduced when water passes through the water heater tank booster. This can result in reduced water pressure at your plumbing fixtures.

Incorrect temperature:

Suppose the thermostatic mixing valve is not installed or adjusted correctly. In that case, it can result in either too hot or too cold water. This can be a safety hazard and result in discomfort for users.

Reduced efficiency:

Adding a tank booster can reduce the efficiency of your water heater. The water heater must work harder to maintain the desired temperature when additional cold water is mixed in.

To avoid these problems, it’s crucial to ensure that the water heater tank booster is installed correctly. You must install it according to the manufacturer’s instructions. Having a licensed plumber install the booster is also an excellent choice to ensure it is installed correctly and safely. Finally, regular maintenance of the booster and your water heater can help prevent problems. The maintenance ensure that your system is working efficiently.

Cropped shot of a handyman repairing a pipe on a water heater
cropped shot of a handyman repairing a pipe on a water heater

Important influencing factors for Heter tank booster

Lifespan

The lifespan of a water heater tank booster can depend on elements such as usage, maintenance, and quality of the product. Yet, on average, a well-maintained water heater tank booster can last around 10-15 years.

Regular maintenance of the booster can help extend its lifespan. This can include flushing out any sediment that may accumulate over time—moreover, checking and tightening any connections to prevent leaks. Constantly inspecting the thermostatic mixing valve to ensure it works correctly.

It’s also important to note that the quality of the product can affect the lifespan of a water heater tank booster. It is investing in a high-quality booster from a reputable manufacturer. Yet, this will help to ensure a longer lifespan and better performance.

Thermostatic mixing valve (Spare parts)

thermostatic mixing valve
Thermostatic mixing valve

This booster mixes cold water with hot water to maintain a consistent temperature. A thermostatic mixing valve is often used to prevent scalding and can also increase the amount of available hot water.

Ultimately, the lifespan of a water heater tank booster will depend on various factors. It includes usage, maintenance, and product quality. Regular maintenance and investing in a quality product can help ensure that your booster lasts for as long as possible.

Tank Boost Valve: (Spare parts)

A Tank Boost Valve, often called a “tank booster” or “mixing valve,” is used with water heater systems, specifically tank-type heaters. Its primary purpose is to ensure that stored hot water remains high enough to prevent bacterial growth (like Legionella) while ensuring that the delivered water temperature to fixtures remains safe to avoid scalding. Here’s a breakdown of its function and importance:

Why Use a Tank Boost Valve?

  • Safety: It ensures that the water coming out of your taps or shower is at a safe temperature, preventing burns and scalds. This is especially important in households with children or elderly individuals.
  • Bacterial Prevention: Storing water at higher temperatures helps minimize the risk of bacterial growth in the water heater, particularly Legionella, which can cause Legionnaires’ disease.
  • Efficiency: With a tank booster, you can get more hot water from your tank without upgrading to a larger tank or adding a water heater.
  • Consistent Temperature: It ensures a constant water temperature at all fixtures, regardless of the usage or demand, making for a more comfortable user experience.

Buying and installation cost of water heater tank booster

The cost of a water heater tank booster can vary depending on the brand, model, and features. Higher-end models with extra features may cost more.

The installation cost will depend on various factors. These are the installation’s complexity, the booster’s location, and the labor cost. Generally, you can expect to pay around $100 to $500 for the professional installation of a water heater tank booster. If you’re comfortable with DIY installations, installing the booster can save labor costs. Yet, ensuring that you have the necessary skills and tools to complete the installation safely and correctly is vital.

Overall, the total cost of a water heater tank booster will depend on the unit’s cost and installation cost. Considering both factors is essential when budgeting for a water heater tank booster. It’s also the best option to shop around. Compare prices and installation costs from different retailers and contractors. This will ensure that you get the best value for your money.
